Power Range (kW): 0.25 - 7.5
No. of Poles: 2P - 8P (speed 2900rpm - 750rpm)
240 Volts 1 Phase 50 Hz
Mountings: Foot / Flange
AC Electric Motor Features:
- IP44 Protection ratings (other ratings e.g. IP56 can be supplied on requst)
- Quality Design
- S1 duty, continous rating
- Capacitor start/capacitor run or capacitor run / induction run for starting torque
- Light Weight (Cast Iron Or Rolled steel)
- Frame sizes: Imperial B56 (0.25kW - 0.75kW) & Metric 90S upto 132M (0.25kW - 7.5kW)
- CastIron Construction (Also avilable rolled steel body with Cast Iron end shields)
- Class F & H Insulations, high quality insulation
- Complaies with AS 1360 for imperial frames
- Complies with AS 1359 for metric frames
- Totally Enclosed Fan Cooled (IC411)
- Thermal manual overload protection via terminal box
- Mounting flexibility - Foot / Flange various positions
- Steel fan cover
- Steel terminal box and capacitor
- High quality bearings, grease packed for life
- High quality and meets stringent requirements
- All Motors are thoroughly tested to ensure their functionality before shipment.
- Our explosion-proof motors Ex d, Ex de have been designed according to European standard Cenelec EN 60079-0:2006; EN 60079-1:2004; EN 61241-1:2004; EN 61241-0:2006 and for this reason they are suitable for hazardous areas as per EN 60079- 10.14.17 standard.
Also complies with all the European standards that Cenelec includes:
IEC 60034-1/2/5/6/7/8/9/12, IEC 60072, IEC 60079-0/1/7, IEC 61241-0, EN 60034-1/2/5/6/7, HD 53 8, EN 60034-9/12 and HD 231.
- Our explosion-proof motors are manufactured in compliance with ATEX standards provided with this mark
- Our explosion-proof motors has been certified for explosion group II A - IIB - IIC and reproduce the following identification marks:
GAS : ZONE 1 e 2 II 2G Ex d, Ex de IIB or IIC
The standard EN 60079-0:2006 and EN 60079-1:2004, state the type of gases and vapours included in each explosion group.
Ex de motors = flameproof enclosure “d” for motor frame and increased safety “e” for terminal box.
DUST: ZONE 21 e 22 II 2D IP66 T 85 °C, T 100° C, T 135 °C, T 155 °C according with standard
EN 60079-7:2007.
- Our explosion-proof motors are certified for the temperature classes T3 - T4 - T5 (some T6). The ATEX standard settles the correlation between temperature class and maximum motor surface temperature, according to the following table:
1Ph Ac Motor Optional Accessories:
- Metric IEC Flange Or Foot Mount (D frame types available)
- VVVF drive for internal speed adjustment
- Slide rails
- Industrial gearboxes
- Couplings
- Chain drives
Applications are endless including:
- Hoists / Winches
- Compressors
- Conveyor Drives
- Pump Drives
- Automation Device
- Food / Pharmacy Packaging
- Pulley drives
- Multi Speed
- Fans
- Food
Suitable for various industries including:
- Power Transmission
- Packaging
- Pharmaceutical
- Automation devices
SAMT can supply all single phase electric motors for all applications. Customised motors and applications can also be accommodated.
